JIS 10K , JIS 20K (15-100A)_Bracket Mount
We believe in Simple & CreativeJIS 10K , JIS 20K (15-100A)_Bracket Mount
KV-04A,04C (Bracket Mount Type)
KV-06A,06C (Bracket Mount Type/Fire Safe Type)
JIS 10 / 20K
2-PC Body, Flanged Ends, Full Port
- Full Port
- 10K (L4A / L6A) & 20K (L4C / L6C)
- Full Port ISO 5211 Mounting Pad
- TFM 1600 Seats
- Size 15-100A
- TA-Luft approved
