EN PN10-40 Reduced Port


KV-L5J(I), L5K(I), L5M(I), L5N(I)
3 & 4 - Way Reduced Port Flanged Ends Ball Valve



  • PN10 - L5J(I), PN16 - L5K(I), PN25 - L5M(I), PN40 - L5N(I)
  • Reduced Port
  • Built-in ISO 5211 Direct Mounting Pad Easy Automation
  • TFM 1600 Seats
  • Size DN100-200
  • TA-Luft Design Approved
