EN PN 10-40_Direct Mount
We believe in Simple & CreativeEN PN 10-40_Direct Mount
KV-L4J,L4K,L4M,L4N (Direct Mount Type)
KV-L6J,L6K,L6M,L6N (Direct Mount Type/Fire Safe Type)
EN PN 10-40
2-PC Body, Flanged Ends, Full Port
- PN10 (L4J / L6J), PN16 (L4K / L6K), PN25 (L4M / L6M), PN40 (L4N / L6N)
- Full Port
- ISO 5211 Pad for Direct Actuation
- TFM 1600 Seats
- Size DN15-200
- TA-LUFT approval
